Senseca UK-040GML0100 Flow Indicator

RangesFlow Meter UK-040Medium water The details in the table correspond to a vertical inwards flow frombelow.Metering range 0.6 - 8 l/h 1.0 - 14 l/h 4.0 - 40 l/h 8.0 - 80 l/h 20.0 - 220 l/hType UK.-040G.W0008 UK.-040G.W0014 UK.-040G.W0040 UK.-040G.W0080 UK.-040G.W0220Medium air The details in the table correspond to a vertical inwards flow frombelow, with the medium at a temperature of 20 °C and a pre-pressure of 1.013 bar.● Frontal scale imprint ● Optionally valve ● Installation plateCharacteristics A float moves in a transparent conical measurement tube, relativeto the flow. The position of the float depends on the volume flow (weight force versus resistance to flow), and indicates the flow rateon the scaled measurement tube.Metering range Qmax. recommended 100 - 1000 cm³/min 1200 cm³/min 0.4 - 5 Nl/min6.0 Nl/min 1.0 - 10 Nl/min 12.0 Nl/min 2.0 - 20 Nl/min 24.0 Nl/min 3.0 - 30 Nl/min36.0 Nl/min 4.0 - 50 Nl/min 60.0 Nl/min 10.0 - 100 Nl/min 120.0 Nl/minType UK.-040G.L0001 UK.-040G.L0005 UK.-040G.L0010 UK.-040G.L0020 UK.-040G.L0030UK.-040G.L0050 UK.-040G.L0100DimensionsTechnical data Switch Nominal width Process connection Metering range Qmax.Tolerance Pressure resistance Medium temperature Ambient temperature MediaElectrical data Materials medium-contactNon-mediumcontact materials Weight Installation locationwithoutDN 4 female thread 1/8 “ NPT 0.6 – 220 l/h H2O 0.1 – 100 NL/min. Air As per metering range.±3 % of full scale valuePN 6 barfor details see table "Ranges"-20..+65 °C -20..+65 °C water, gases none Brass construction:Stainless steel acrylic, glass, construction:1.4305, 1.4310, acrylic, glass, CW614N, NBR 1.4305, 1.4310, FKM acrylic, CW614N, PSvalve: ABS, CW614N 0.24 kg vertical inwards flow from belowdsh_fam_uk-040_en_vs011
