Senseca NJVM2-025GM060 Flow Switch

Flow Switch944653Nominal diameter: DN 25Connection type: Female thread G 1Connection material: Brass nickel-platedPressure resistance: PN 100Seal: NBRMedia temperature: -20 ... +100 °CEnvironmental temperature: -20 ... +70 °COil display range: 10 ... 60 l/min oil 1 ... 200 mm²/sScale: 1 ... 200 mm²/sSwitching range oil: 10 ... 60 l/min oil 1 ... 200 mm²/sSwitching head: MetalElectrical connection: Pg 9 with 2.5 m cableElectrical contact: Reed switchMax. contact load: 250 V AC 0.5 A 10 VAConnection diagram: Connection diagram no. 0.215 (NJE 200)Protection type: IP65Flow direction: Vertically from below
