Senseca HD2K-010GM008 Flow Switch

Flow Switch953117Version: Viscosity compensatedIndicator options: Without mechanical indicatorNominal diameter: DN 10 - G ⅜Connection type: Female threadConnection material: Brass CW614N nickel-platedSeal: NBRPressure resistance: PN 200Media temperature: -20 ... +120 °CEnvironmental temperature: -20 ... +70 °CSwitching range oil: 0.5 ... 8 l/min oil 30 ... 330 mm²/sSwitching head: PlasticAdjustment: Pinion, scale min.-max.Electrical connection: Plug DIN 43650-A / ISO 4400Electrical contact: Reed switchMax. contact load: 120 V AC 0,18 A 5 VA / 175 V DC 0,25 A 5 WConnection diagram: Changeover, connection diagram no. 0.213Protection type: IP65Flow direction: Horizontal from the left
