Senseca 7012/J-1-2L-6-W-15-180-VK17-5000-400°C Temperature Probe 7012/j

Temperature Sensor 7012 / 7112Ordering code 1.2.-3.-4.-5.-6.-7.-8.-9.-10.-11.-1.Characteristics ● ● ● ● ●Thermocouple Fe-CuNi (type J); NiCr-Ni (type K)RTD Pt100, class B Thermowell material stainless steel 1.4571 Measuring tip plane or angle 120°Cable type flexible fiberglass insulation with steel wire brading or Teflon-Silicon-insulationDimensionsAccessories Description Thread adapter M10x1 Thread adapter M12x1 Thread adapter M12x1.75Thermowell R ¼ 30 mm length Thermowell R ¼ 100 mm lengthpi-ma-7012_7112_E V3.01-00Ordering code GN-40 GN-41 GN-49 (standard)THR ¼ -SW17THR ¼ -SW17-100Measuring element 7012/J thermocouple Fe-CuNi (type J) 7012/K thermocouple NiCr-Ni (type K)7112 Pt100 class B2. Number of elements 1 23. Connection type 2L 2-wire 3L 3-wire (only 7112, Pt100 ) 4L 4-wire (only 7112, Pt100 )4. Measuring tip diameter 6 6 mm 8 8 mm5. Measuring tip type P plane (flat tip) W angle 120°6. Installation length 15 15mm7. Spring length without 180 180mm 250 250mm8. Bayonet lock type VK14 inner diameter 12.2mm VK17 inner diameter 14.5mm9. Cable type insulation EGL flexible fiberglass with steel wire braidingTe-Si Teflon-Silicon up to 180°C10. Cable length (please state in clear text) X length in mm11. Operating temperature 180°C Teflon-Silicon-insulation 400°C Fiberglass insulation(other versions on request)Stock 7012/J-1-2L-6-W-15-180-VK17-EGL-2000-400°C 7012/J-1-2L-8-W-15-180-VK17-EGL-2000-400°C7112-1-2L-6-P-15-180-VK17-EGL-2000-400°C 7112-1-2L-6-W-15-180-VK17-EGL-2000-400°C7112-1-2L-8-P-15-180-VK17-EGL-2000-400°C 7112-1-2L-8-W-15-180-VK17-EGL-2000-400°C7112-2-2L-6-W-15-180-VK17-EGL-2000-400°C 7112-2-2L-8-W-15-180-VK17-EGL-2000-400°C1
